Coated Fasteners

Coated Fasteners Manufacturer, Coated Fasteners Stockist, Coated Fasteners Supplier, Coated Fasteners Exporter - Petroinox India

Ananka Group is the best leading Coated Fastener Manufacturer in India. We have a wide range of Washers, with ready stock for export and supply. As, we are the Specialized Coated Fastener Manufacturer in India. We take orders and manufacture as per the customers’ requirements. Ananka Group has a life expectancy years beyond the competition in highly corrosive offshore, energy industrial environments, NanoGalv Fasteners out-perform all currently-specified fastener coatings used in oil and gas.

NanoGalv provides:
• Over 10x corrosion resistance of commonly used systems
• Reduced maintenance
• Less expensive up-front cost over exotic alloys
• Abrasion resistance superior to easily damaged coating systems
• Removal of toxic cadmium plating and hex chrome passivates
• Reduced downtime and increased production

Types of Coated Fasteners

Specification of PTFE Coated Bolts

Standards	Designation
ASTM	PTFE Coated
Thread Requirements of PTFE Coated Bolts	UNC & UNF, ASME B1.1, Class 2A (Fastenal will inspect and accept parts with a 1A no-go gauge)
PTFE Coated Bolts Manufacturing Process	Cold Heading, Wire Drawing, Heat Treatment, Insert tapping, Inspection, Surface Plating, Packing
PTFE Coated Bolts Delivery time	Custom product will according to special requirement, Regular product is about 7-15 days
PTFE Coated Bolts Coatings	PTFE
PTFE Coated Bolts Head	Square, Hex, Hex flange, Round, T-head, Flat & Triangular, etc
PTFE CoatedM Bolts Neck type	Square, Hex, Oval, Triangular & Knurled, etc
PTFE Coated Bolts Dimensions	ASME B18.3, B18.2.1
Melt Origin	South America/East Europe/Japan/Korea
Product Origin	Made in India
PTFE Coated Bolts Threads Configuration	B1.13M 6h Metric Coarse Threads and ASME B1.1 2A/3A Inch Unified Threads
PTFE Coated Bolts Certification	Dual Certified As per ASME & ASTM Codes
Additional Certifications	Merkblatt AD 2000 W2 Certified, PED 97/23/EC Certified
Mandatory Requirements	Free from Radioactive & Mercury Contamination
Additional Requirements	NACE MR0175 / MR0103 /ISO 15156 Compliance
PTFE Coated Bolts Samples	Yes
Payment Terms	Western Union, T/T, Paypal, Trade Assurance 30% deposit & balance before shipping or L/C

PTFE Coated Bolt Torque Chart

BOLT DIA	Torque FT-LBS
BOLT DIA	30% Initial Torque	70% Torque	100% Final Torque
1/2	16	36	52
9/16	23	53	75
5/8	31	73	104
3/4	55	129	184
7/8	71	166	237
1	107	249	356
1.1/8	127	297	424
1.1/4	179	417	596
1.3/8	186	435	622
1.1/2	246	574	821
1.9/16	168	392	560
1.5/8	191	445	636
1.3/4	240	561	801
1.7/8	298	696	994
2	366	853	1219
2.1/4	529	1234	1762
2.1/2	733	1709	2442
2.3/4	986	2300	3285
3	1289	3008	4297

BOLT DIA	Torque Nm
BOLT DIA	30% Initial Torque	70% Torque	100% Final Torque
1/2	22	49	71
9/16	31	72	102
5/8	42	99	141
3/4	75	175	249
7/8	96	225	321
1	145	338	483
1.1/8	172	403	575
1.1/4	243	565	808
1.3/8	252	590	843
1.1/2	334	778	1113
1.9/16	228	531	759
1.5/8	259	603	862
1.3/4	325	761	1086
1.7/8	404	944	1348
2	496	1157	1653
2.1/4	717	1673	2389
2.1/2	994	2317	3311
2.3/4	1337	3118	4454
3	1748	4078	5826
